Key Features:
High Brightness Display:
- Up to 8,000 nits — clearly visible in direct sunlight, day and night
- Automatic day/night brightness control for optimal visibility at all hours
- LED or fibre-optic display technology available
- Wide viewing angles up to ±40° for maximum roadside coverage
- Full-color LED option for rich graphics and multi-colour messaging
Remote Control & Management:
- Web and app-based management — update messages instantly from anywhere
- Displays text, symbols and graphics in real time
- Integrates with traffic sensors, weather stations and IoT feeds for automated updates
- Schedule messages in advance or trigger them from live sensor data
- Colour-coded severity levels: red alerts, amber warnings, green advisories
Energy Efficient & Weatherproof:
- LED technology cuts power consumption by up to 70% compared to traditional signs
- IP65-rated weatherproof housing — dust, rain and humidity proof
- Operating temperature range: −20°C to +60°C (Advanced model)
- Standard model: ≤ 250 W, Advanced model: ≤ 450 W power consumption
- Designed for continuous 24/7 outdoor operation in all climates
Modular & Easy to Maintain:
- Modular panel design allows fast swap-out without downtime
- Up to 100,000-hour LED lifespan (Advanced model), 50,000 hours (Standard)
- Field-serviceable components for minimal maintenance overhead
- Individual LED matrix modules can be replaced independently
- Reduces total cost of ownership over the product lifecycle
Technical Specifications:
Standard Model:
- Display technology: Tri-color LED
- Pixel pitch: 20 mm
- Brightness: 4,000 nits
- Viewing angle: ±30°
- IP rating: IP54
- Operating temperature: −10°C to +50°C
- Communication: LAN
- Power consumption: ≤ 250 W
- LED lifespan: 50,000 hours
Advanced Model:
- Display technology: Full-color LED
- Pixel pitch: 10 mm / 16 mm
- Brightness: 8,000 nits
- Viewing angle: ±40°
- IP rating: IP65
- Operating temperature: −20°C to +60°C
- Communication: Fibre / Wi-Fi
- Power consumption: ≤ 450 W
- LED lifespan: 100,000 hours
LED Matrix Configurations:
- 8 × 32 (rows × cols) — Compact: speed alerts and single-word messages
- 16 × 64 — Standard: multi-word highway signs and lane indicators
- 8 × 96 — Wide banner: full-sentence scrolling messages
- 24 × 128 — Large format: smart city displays and portal frames
- Custom matrix sizes available on request
Message Capabilities:
- Speed alerts with colour-coded severity (red/amber/green)
- Lane closure and detour information messages
- Weather warnings and hazard advisory notifications
- Custom text, symbols and graphics support
- Scheduled and sensor-triggered message automation
- Multi-line and scrolling message modes
Applications & Architecture:
Highway & Motorway:
- Speed limit enforcement and variable speed zone signage
- Lane control indicators and lane closure alerts
- Incident and accident warnings for approaching drivers
- Work zone safety messages and detour routing
- Real-time traffic condition and congestion updates
Smart City & Urban:
- Parking guidance with real-time space availability
- Air quality index and environmental monitoring data
- Public transport arrival times and route information
- Event information, emergency broadcasts and public announcements
- Weather condition displays at key city intersections
Railways, Airports & Industrial:
- Departure boards and platform/gate information displays
- Emergency evacuation instructions and safety alerts
- Port and yard vehicle management and hazard warnings
- Construction zone worker safety messages and detour signs
- Industrial facility status boards and shift information
System Architecture:
- Data Sources: traffic sensors, weather stations, IoT devices feed live data
- Central Server: processes incoming data and generates display messages
- Network Layer: messages pushed over secure Fibre or LAN connections
- VMS Controller: edge device at each sign location receives and renders messages
- Display Board: LED panel shows the final output to drivers and pedestrians
- End-to-end ecosystem from sensor input to on-road display output
Product Walkthrough:
